MG6S Plus Series

Fast Installation, Intelligent Selection

Pixel Pitch: 1.9/2.6/2.8/3.9/4.8/5.2mm

Cabinet Size: 500*750*73mm

Operating Environment: Indoor

Request A Solution
Wise Choice for Indoor Rental

The world's first application of nano polymer materials in the field of LED screen, the cabinet is tough and strong, light and easy.

The Anti-collision Ability Increased by 100%

Adopt linear secondary adhesion process strengthen the adhesive force of LEDs.

Light Weight

The cabinet is light and thin, which saves time and effort for installation.

Front and Rear Maintenance

Hard connection wireless design is adopted inside the cabinet, the back cover is designed with pin, and modules, power supply and receiving card which can be removed and replaced quickly.

Outstanding Image Quality

Elaborately selected brand LEDs and high gray high refresh IC, matching with superior control system, and adopting HDR technology, the screen could reach 18 bits gray scale.

Application Scenarios

Wide application: Indoor concerts, awards ceremony, conference, indoor sports events, etc.

Parameters

DOWNLOAD
Contact us for more parameters
Pixel Pitch (mm) 1.9 2.6 2.8 3.9 4.8 5.2
Operating Environment Indoor Indoor Indoor Indoor Indoor Indoor
Module Size (mm) 250*250 250*250 250*250 250*250 250*250 250*250
Cabinet Size (mm) 500*750*73 500*750*73 500*750*73 500*750*73 500*750*73 500*750*73
Cabinet Resolution (W×H) 256*384 192*288 176*264 128×192 96×144 96×144
IP Grade IP50 IP50 IP50 IP50 IP50 IP50
Weight (kg/cabinet) 8.3 8.3 8.2 7.6 7.5 7.5
White Balance Brightness (nit) 500-700 800-1000 800-1000 800-1000 800-1000 800-1000
Horizontal / Vertical Viewing Angle 160/160 160/160 160/120 160/120 160/120 160/120
Power Consumption(W/㎡) 400±15%/105±15% 450±15%/150±15% 420±15%/140±15% 420±15%/140±15% 420±15%/140±15% 420±15%/140±15%
Refresh Rate(Hz) ≥1920(1920,2880,3840...) ≥1920(1920,2880,3840...) ≥1920(1920,2880,3840...) ≥1920(1920,2880,3840...) ≥1920(1920,2880,3840...) ≥1920(1920,2880,3840...)
Control System Nova Nova Nova Nova Nova Nova
Certification CE, FCC, ETL CE, FCC, ETL CE, FCC, ETL CE, FCC, ETL CE, FCC, ETL CE, FCC, ETL
